34
Technical Information
Service Manual
xed angle.
● Hold " " button above 2s to set your required swing angle.
When reaching your required angle, release the button.
NOTE:
● " , , " may not be available. When air conditioner
receives this signal, the air conditioner will blow fan automatically.
● Press this button continuously more than 2s, the main unit
will swing back and forth from up to down, and then loosen the
button, the unit will stop swinging and present position of guide
louver will be kept immediately.
● Under swing up and down mode, when the status is switched
from off to , if press this button again 2s later, status will
switch to off status directly; if press this button again within 2s,
the change of swing status will also depend on the circulation
sequence stated above.
8. T-ON / T-OFF button
● T-ON button
"T-ON" button can set the time for timer on. After pressing this
button, " " icon disappears and the word "ON" on remote
controller blinks. Press " " or " " button to adjust T-ON setting.
After each pressing " " or " " button, T-ON setting will increase
or decrease 1min. Hold " " or " " button, 2s later, the time will
change quickly until reaching your required time. Press "T-ON"
to conrm it. The word "ON" will stop blinking." " icon resumes
displaying. Cancel T-ON: Under the condition that T-ON is started
up, press "T-ON" button to cancel it.
● T-OFF button
"T-OFF" button can set the time for timer off. After pressing this
button, " " icon disappears and the word "OFF" on remote
controller blinks. Press " " or " " button to adjust T-OFF setting.
After each pressing " " or " " button, T-OFF setting will increase
or decrease 1min. Hold " " or " " button, 2s later, the time will
change quickly until reaching your required time. Press "T-OFF"
word "OFF" will stop blinking. " " icon resumes displaying.
Cancel T-OFF: Under the condition that T-OFF is started up,
press "T-OFF" button to cancel it.
NOTE:
● Under on and off status, you can set T-OFF or T-ON
simultaneously.
● Before setting T-ON or T-OFF, please adjust the clock time.
● After starting up T-ON or T-OFF, set the constant circulating
valid.
● After that, air conditioner will be turned on or turned off
according to setting time. ON/OFF button has no effect on setting.
If you don’t need this function, please use remote controller to
cancel it.
9. I FEEL button
Press this button to start I FEEL function and " " will be
displayed on the remote controller. After this function is set, the
remote controller will send the detected ambient temperature
to the controller and the unit will automatically adjust the indoor
temperature according to the detected temperature. Press this
button again to cancel I FEEL function and " " will disappear.
● Please put the remote controller near user when this function
is set. Do not put the remote contro ller near the object of high
temperature or low temperature in order to avoid detecting
inaccurate amb ient temperature. When I FEEL function is turned
on, the remote controller should be put within the area where
indoor unit can receive the signal sent by the remote controller.
10. CLOCK button
Press this button to set clock time. " " icon on remote controller
will blink. Press "▲" or " ▼ " button within 5s to set clock time.
Each pressing of "▲" or " ▼ " button, clock time will increase or
decrease 1 minute. If hold "▲" or " ▼ " button, 2s later, time will
change quickly. Release this button when reaching your required
time. Press "CLOCK" button to conrm the time. " " icon stops
blinking.
NOTE:
● Clock time adopts 24-hour mode.
● The interval between two operations can't exceed 5s.
Otherwise, remote controller will quit setting status. Operation for
T-ON/T-OFF is the same.
11. SLEEP button
● Press this button, can select Sleep 1 ( 1), Sleep 2 ( 2),
Sleep 3 ( 3) and cancel the Sleep, circulate between these,
after electried, Sleep Cancel is defaulted.
● Sleep 1 is Sleep mode 1, in Cool modes; sleep status after run
for one hour, the main unit setting temperature will increase 1 ,
two hours, setting temperature increased 2°C, then the unit will
run at this setting temperature; In Heat mode: sleep status after
run for one hour, the setting temperature will decrease 1 , two
hours, setting temperature will decrease 2 , then the unit will run
at this setting temperature.
● Sleep 2 is sleep mode 2, that is air conditioner will run
according to the presetting a group of sleep temperature curve.
● Sleep 3-the sleep curve setting under Sleep mode by DIY;
(1) Under Sleep 3 mode, press “Turbo” button for a long
time, remote controller enters into user individuation sleep
setting status, at this time, the time of remote controller will
display “1hour”, the setting temperature “88” will display the
corresponding temperature of last setting sleep curve and blink
(The rst entering will display according to the initial curve setting
value of original factory);
(2) Adjust “+” and “-” button, could change the corresponding
setting temperature, after adjusted, press “Turbo” button for
conrmation;
