98
Installation and Maintenance
NO. Description Qty
1 Front Grill 1
2 Front Panel 1
3 Axial Flow Fan 1
4 Chassis Sub-assy 1
5 Compressor and Fittings 1
6 Electronic Expansion Valve Assy 1
7 Right Side Plate 1
8 Valve Support 1
9 Cut-off valve 1/4(N) 1
10 Cut-off valve 5/8(N) 1
10 Valve Cover 1
11 Handle 1
12 Terminal Board 1
14 4-Way Valve Assy 1
15 Condenser Assy 1
16 Clapboard Assy 1
17 Motor Support 1
18 Brushless DC Motor 1
19 Top Cover Assy 1
20 Left Side Plate 1
21 Condenser Left Border Plate 1
22 Electric Box Assy 1
23 Radiator 1
24 Electric Box 1
25 Main Board 1
26 Electric Box Cover 1
Some models may not contain some parts, please refer to the actual product.
