118
Installation and Maintenance
Step Procedure
12. Remove motor support
Remove the screws xing the motor support and lift the
motor support to remove it.
14. Remove clapboard assy
Remove the screws xing the clapboard assy and then
remove the clapboard assy.
15. Remove compressor
Remove the 3 foot nuts on the compressor and then
remove the compressor.
motor support
clapboard assy
compressor
nut
To Next Page
