Disassembly of Outdoor Unit
42,000 btuh Warning - Wait 10 minutes aer power is disconnected before starting disassembly.
Disassembly of the Electronic Expansion Valve
1. Remove EEV coil
Remove the coil by rotating until it is unlocked.
2. Disconnect the tubing
Reclaim all refrigerant from system before removing tubing.
Follow proper procedure to disconnect tubing from EEV. Keep
debris and moisture from entering system.
Disassembly of the Vapor/Liquid Separator
1. Disconnect piping
Reclaim all refrigerant from system before removing tubing.
Remove tubing from separator, then remove the separator. Keep
debris and moisture from entering system.
