4.3.5.8 Branch selection of downstream indoor unit of mode exchanger (“B1,B2, B3”)
Total rated capacity of downstream indoor units: X(Btu/h)
4.3.5.9 Pipe size between mode exchanger and downstream indoor unit (“b, c, d, g”)
Total rated capacity of downstream indoor
units: X (Btu/h)
Piping size between indoor branches
4.3.5.10 Pipe size between indoor branch and indoor unit (“e, f, i, j, k”)
Rated capacity of indoor units:
X ((Btu/h)
Size of connection pipe between indoor branch and indoor unit
4.3.5.11 Pipe size between indoor branches (“I”)
Rated capacity of indoor units:
X ((Btu/h)
Size of connection pipe between indoor branch and indoor unit
4.3.6 Connection method when capacity of indoor unit exceeds 48500 Btu/h
When connecting to the indoor unit with capacity of over 48500 Btu/h, it is not allowed to connect
with only one branch; it must use two branches controlled by the same main board for parallel
connection.
Indoor unit communication connection
for mode exchanger
Indoor unit No.1 and No.2
Parallel connection can be conducted
only as the combination of this table, it
is not allowed to otherwise connect.
Note that after the connection,
manually set the SA2 dial code of
corresponding main board, and dial
the code in the first place to number
end.
Indoor unit No.3 and No.4
Indoor unit No.5 and No.6
Indoor unit No.7 and No.8
