Multi-Blade Fire and Combination Fire Smoke Dampers4
Clearances Required Between Damper Sleeves & Wall/Floor Openings
Two-Sided Angle Installation
Two-sided angle installations require clearances for thermal expansion between the damper sleeve and the wall/floor
opening. The minimum required clearances are:
• For galvanized steel dampers and sleeves:
1
⁄8 in. per foot (3 mm per .3 m) of damper width and
1
⁄8 in. per foot (3
mm per .3 m) height with a minimum clearance of
1
⁄4 in. (6 mm). The total gap may be up to 6 in. (152 mm)
larger than the damper, with a maximum gap between the damper and the opening of 3 in. (76 mm) per side as
long as the retaining angles overlap the wall/floor by a minimum of 1 in. (25 mm).
• For stainless steel dampers and stainless steel or galvanized sleeves:
3
⁄16 in. per foot (5 mm per .3 m) of damper
width and height with a minimum clearance of ¼ in. (6 mm), maximum of 2 in. (51 mm).
These are total clearances (ignoring fastener heads) and do not need to be equally spaced around the damper.
Although the minimum requirements are listed above, for ease of installation the following are the recommended
clearances for galvanized dampers:
• Width/Height of 48 in. (1219 mm) or less - ½ in. (13 mm) clearance
• Width/Height between 48.01 in. (1220 mm) and 96 in. (2438 mm): 1 in. (25 mm) clearance
• Width/Height greater than 96 in. (2438 mm): 1½ in. (38 mm) clearance
Example:
A 12 in. x 12 in. (305 mm x 305 mm) will
require a minimum clearance of ¼ in.
(6 mm) width and ¼ in. (6 mm) on height
A 48 in. x 12 in. (1219 mm x 305 mm)
damper will required a minimum clearance
of ½ in. (13 mm) on width and ¼ in. (6 mm)
on height.
Single Side Angle Installation
On vertical mount single side angle installations there are no minimum clearance requirements between the wall
opening and the damper sleeve. However, to facilitate installation, the width and height of the opening in the wall
may be up to 1
1
⁄2 in. (38 mm) greater than the width and height of the damper.
On horizontal mount single side angle installations a minimum clearance is required between the outside of the
damper sleeve and the floor opening of
1
⁄8 in. per foot (3 mm per .3 m) of damper width and
1
⁄8 in. per foot
(3 mm per .3 m) height with a minimum clearance of ¼ in. (6 mm). The width and height of the opening in the floor
may be up to 1
1
⁄2 in. (38 mm) greater than the width and height of the damper.
Installing Multiple Section Damper Assemblies
A damper assembly is not restricted to a maximum number of sections, but must not exceed the section sizes and
overall sizes shown (see chart on page 5).
Some multiple section high damper assemblies require additional structural support between the damper frames.
The following multiple section high damper assemblies require the use of either a support mullion between the
damper frames as shown in Figure 5 or individual sleeves around each row of dampers as shown in Figure 6:
• All horizontal mount dampers
• All vertical mount dampers over 72 in. (1829 mm) high and greater than 2 sections wide
• All vertical mount dampers rated for more than 4 in. wg (1 kPa)
• All vertical mount dampers that use fusible links as a closure device
The damper sections must be attached together with #10 (¾ in. max. [19 mm]) sheet metal screws, ¼ in. (6 mm)
diameter nuts and bolts, tack or spot welds, or
3
⁄16 in. (48 mm) diameter steel pop rivets. Attachments must be
spaced a maximum of 6 in. (152 mm) O.C. and a maximum of 2 in. (51 mm) from corners. Attachments must be
made on front face and back face (air entering and air exiting side) of damper sections.
Note: Dampers ordered for individual installation may not be installed together. The full assembly size must be
specified at the time the dampers are ordered.
