1399 and 1399-22 Band Saws
Parts List—Bed and Leg Details
KEY PART NO. DESCRIPTION QTY.
1 503 2213.3 Hand Wheel........................................................................ 1
2 905 3420.4 Nut, hex, 1 - 8, jam............................................................. 1
3 503 2188.9 Thrust collar ....................................................................... 1
4 503 2115.0 Vise screw .......................................................................... 1
5 503 2214.1 Vise screw nut .................................................................... 1
6 503 2216.8 Vise ratchet ........................................................................ 1
7 503 2217.6 Clamp block........................................................................ 1
8 905 0699.5 Pin, roll, .187 x 1.00 ........................................................... 2
9 905 0523.9 Screw, cap, 5/16 - 18 x 1-1/4 hex head............................. 4
10 503 2218.4 Ratchet dog, vise ............................................................... 1
11 905 3421.2 Pin, roll, .375 x 2.50 ........................................................... 1
12 503 2219.2 Vise jaw, movable .............................................................. 1
13 905 0549.2 Screw, cap, 1/2 - 13 x 2-1/2 hex head............................... 1
14 905 0544.1 Screw, cap, 1/2 - 13 x 1-1/2 hex head............................... 6
15 905 1107.7 Washer, .500 x 1.25 x .084 flat .......................................... 6
16 503 2220.6 Vise jaw, stationary ............................................................ 1
17 905 0547.6 Screw, cap, 1/2 - 13 x 2 hex head ..................................... 1
18 503 2174.9 Pin, locating........................................................................ 2
19 503 2221.4 Nut, clamp .......................................................................... 1
20 503 2222.2 Vise slide block .................................................................. 1
21 503 2223.0 Vise slide block guide ........................................................ 1
24 503 2224.9 Bed ..................................................................................... 1
25 503 2225.7 Tip-off block........................................................................ 1
26 905 0505.0 Washer, lock, .323 x .586 x .078 spring ............................ 4
27 905 0521.2 Screw, cap, 5/16 - 18 x 3/4 hex head ................................ 2
28 503 2371.7 Bracket, dash pot ............................................................... 1
35 503 2227.3 Leg, drive end .................................................................... 1
36 905 2793.3 Washer, lock, .516 x .873 x .125 spring ............................ 4
37 905 3169.8 Screw, thumb, 1/4 - 20 x 1/2 .............................................. 2
38 503 2228.1 Axle..................................................................................... 1
39 503 2229.0 Mounting block ................................................................... 2
40 503 2230.3 Leg, idle end....................................................................... 1
41 503 2231.1 Wheel ................................................................................. 2
42 905 2396.2 Nut, hex, 5/8 - 11 lock head ............................................... 2
44 503 2232.0 Grip, handle........................................................................ 1
45 503 2233.8 Handle rod .......................................................................... 1
47 503 2317.2 Latch................................................................................... 1
49 503 2234.6 Collar .................................................................................. 3
50 905 1035.6 Screw, set, 1/4 - 20 x 3/16 flat point socket....................... 3
52 503 2235.4 Ratchet dog ........................................................................ 1
53 905 0647.2 Nut, hex, 1/2 - 13 jam......................................................... 1
56 503 2236.2 Stop latch ........................................................................... 1
57 905 3423.9 Washer, flat, .344 x .688 x .065 ......................................... 2
58 905 0654.5 Pin, cotter, .125 x 1.00 ....................................................... 2
59 503 2237.0 Vertical Work Table, (optional) .......................................... 1
60 503 2206.0 Hook, safety ....................................................................... 1
61 503 2205.2 Chain .................................................................................. 1
62 905 1267.7 Screw, self-tapping, #10 - 12 x 5/8 type A panhead ......... 1
63 503 9919.5 Vise face plate, movable (older units only)........................ 1
64 503 9920.9 Vise face plate, stationary (older units only)...................... 1
Repair Kit:
503 2239.7 Wheel and Handle Kit (includes 23, 26, 38, 39, 41, 42, 44-51, 56- 58)
