Greenlee 1399 - Blade Guides and Gear Box Details

Greenlee Textron / Subsidiary of Textron Inc.
23
4455 Boeing Dr., Rockford, IL 61109-2988 815/397-7070
1399 and 1399-22 Band Saws
Parts List—Blade Guides and Gear Box Details
KEY PART NO. DESCRIPTION QTY.
1 503 2263.0 Gear case ........................................................................... 1
2 503 2158.7 Cover, gear case ................................................................ 1
3 905 3427.1 Retaining ring ..................................................................... 1
4 503 2155.2 Plug, expansion.................................................................. 1
5 905 3429.8 Ball bearing ........................................................................ 1
6 503 2156.0 Shaft, pulley ....................................................................... 1
7 503 2157.9 Key ..................................................................................... 1
8 905 3406.9 Ball bearing ........................................................................ 1
9 905 3432.8 Retaining ring ..................................................................... 1
10 905 0610.3 Screw, set, 5/16 - 18 x 3/8 socket ..................................... 3
11 503 2165.0 Pulley.................................................................................. 1
12 503 2166.8 “V” belt (115-volt models) .................................................. 1
503 2368.7 “V” belt (220-volt models) .................................................. 1
13 503 2161.7 Gear, driven ....................................................................... 1
14 905 3433.6 Ball bearing ........................................................................ 2
15 503 2264.8 Drive shaft .......................................................................... 1
16 905 3434.4 Screw, cap, 5/16 - 18 x 7/8 hex head ................................ 3
17 905 0505.0 Washer, lock, .323 x .586 x .078 spring ............................ 3
18 905 1918.3 Screw, cap, 1/4 - 20 x 1-1/2 socket head .......................... 2
19 503 2265.6 Drive pinion ........................................................................ 1
20 905 0699.5 Pin, roll, .187 x 1 ................................................................ 1
21 503 2138.2 Slide block .......................................................................... 1
22 905 1265.0 Screw, cap, 1/4 - 20 x 3/4 socket head ............................. 4
23 503 2266.4 Guide bracket, idle end ...................................................... 1
24 503 2139.0 Wing screw ......................................................................... 1
25 503 3886.2 Blade guard ........................................................................ 1
28 503 2140.4 Roller support ..................................................................... 2
29 905 2125.0 Washer, flat, .281 x .625 x .065 ......................................... 4
30 905 1674.5 Washer, lock, .259 x .489 x .062 spring ............................ 4
31 905 0520.4 Screw, cap, 1/4 - 20 x 3/4 hex head .................................. 4
32 905 3435.2 Ball bearing ........................................................................ 6
33 905 3423.9 Washer, flat, .344 x .688 x .065 ......................................... 6
34 503 2143.9 Axle, eccentric roller........................................................... 2
35 503 2141.2 Roller axle .......................................................................... 3
36 503 2144.7 Nut, eccentric axle ............................................................. 2
37 503 2269.9 Guide bracket, drive end.................................................... 1
38 503 2270.2 Blade brush angle (long) .................................................... 1
39 503 2271.0 Blade brush angle (short)................................................... 1
40 503 2272.9 Blade brush ........................................................................ 2
41 503 2273.7 Weld bolt ............................................................................ 2
42 905 3436.0 Nut, hex, 1/4 - 20................................................................ 2
43 905 3437.9 Screw, machine, #10 - 32 x 1-1/8 round head .................. 4
44 905 0178.0 Washer, lock, .198 x .320 x .040 spring ............................ 4
45 905 1686.9 Nut, hex, #10 - 32............................................................... 4
46 503 2274.5 Blade guard, stationary ...................................................... 1
47 503 2142.0 Axle, roller .......................................................................... 1
48 905 3408.5 Nut, wing, 1/4 - 20 .............................................................. 1
49 905 3495.6 Screw, cap, 1/4 - 20 x 2.00 socket head ........................... 2
50 905 0637.5 Nut, hex, 1/4 - 20................................................................ 2
