Greenlee Textron / Subsidiary of Textron Inc.

4455 Boeing Dr., Rockford, IL 61109-2988 815/397-7070

1399 and 1399-22 Band Saws

Parts List—Wheel and Frame Details (cont’d)

KEY PART NO. DESCRIPTION QTY.

39 503 2258.3 Guard, angle wheel ............................................................ 1

40 503 2259.1 Guard, end ......................................................................... 1

41 503 2260.5 Wheel guard, short ............................................................. 1

42 905 0863.7 Screw, cap, 3/8 - 16 x 7/8 hex head .................................. 1

43 905 0506.9 Washer, lock, .388 x .673 x .070 steel............................... 2

44 905 0538.7 Screw, cap, 3/8 - 16 x 3 hex head ..................................... 1

45 905 2553.1 Washer, flat, .375 ID x .030 ............................................... 1

46 905 1435.1 Nut, hex, 3/8 - 16................................................................ 1

47 503 2132.3 Spacer ................................................................................ 1

48 503 2256.7 Spacer ................................................................................ 1

49 905 0523.9 Screw, 5/16 - 18 x 1-1/4 hex head..................................... 1

Repair Kit

503 2261.3 Idler Wheel Assembly, Complete (includes items 11 - 15)

503 2262.1 Drive Wheel Assembly, Complete (includes items 12 - 15 and 17 - 20)
