1399 and 1399-22 Band Saws
Appendix B - Vertical Work Table (optional)
Assembly
1. Disconnect the saw from the power supply.
2. Raise the cutting head.
3. Remove the Caution decal.
4. Position the support as shown. Attach the support to
the saw bed with two 5/16 - 18 x 1" cap screws.
5. Attach the table to the support with the bolts,
washers, and nuts provided.
6. Adjust the set screws to level the table.
Do not inspect, adjust, or service the tool or raise
the cutting head while it is connected to a power
source. Accidental starting can result in injury.
Keep hands away from the blade
and cutting area during operation.
Pinch points.
The cutting head, blade wheels
and drive belt can cause injury
when making adjustments.
Failure to observe this warning
can cause severe injury or death.
