Greenlee 1399 - Page 25

Greenlee Textron / Subsidiary of Textron Inc.
25
4455 Boeing Dr., Rockford, IL 61109-2988 815/397-7070
1399 and 1399-22 Band Saws
KEY PART NO. DESCRIPTION QTY.
503 2322.9 Wet Cutting System (includes items 1 - 22 for 115-volt systems;
220-volt systems also include items 65 - 67) .................... 1
1 503 2280.0 Chip pan (includes item 2) ................................................. 1
2 503 2284.2 Splash guard ...................................................................... 1
3 503 2282.6 Coolant tank (includes cover) ............................................ 1
4 503 2283.4 Screen ................................................................................ 1
5 503 4304.1 Mounting bracket................................................................ 1
6 503 2287.7 Coolant pump ..................................................................... 1
7 503 2292.3 Coolant nozzle ................................................................... 1
8 503 2290.7 Needle valve ...................................................................... 1
9 503 2288.5 Adapter ............................................................................... 2
10 503 2291.5 Hose clamp ........................................................................ 2
11 503 2289.3 Coolant hose ...................................................................... 1
12 905 3589.5 Hose strap .......................................................................... 3
13 905 1185.9 Screw, machine, 1/4 - 20 x 1/2 round head....................... 2
14 905 0704.5 Screw, machine, #10 - 32 x 3/8 round head...................... 2
15 905 1369.8 Screw, thumb, 1/4 - 20 x 1/2 ............................................. 2
16 905 2707.0 Washer, .281 x .625 x .062 ................................................ 4
17 905 2626.0 Screw, machine, #10 - 32 x 1/2 round head...................... 4
18 905 0178.0 Washer, lock, .198 x .320 x .040 spring ............................ 6
19 905 1686.9 Nut, hex, #10 - 32............................................................... 6
20 905 0521.2 Screw, cap 5/16 - 18 x 3/4 hex head ................................. 5
21 905 0505.0 Washer, lock, .323 x .586 x .078 spring ............................ 5
22 918 6347.3 Cord set, 115-volt............................................................... 1
24 503 2293.1 Switch box .......................................................................... 1
25 503 2295.8 Cover, switch box ............................................................... 1
26 503 2191.9 Switch, toggle ..................................................................... 1
27 503 2192.7 Switch, push-button (thermal) ............................................ 1
28 503 2195.1 Guard, push-button switch ................................................. 1
29 918 6348.1 Relay .................................................................................. 1
30 503 2196.0 Cord and terminal assembly .............................................. 1
31 503 2197.8 Cord and plug, 115-volt...................................................... 1
32 503 2193.5 Lever, shut-off .................................................................... 1
33 503 2194.3 Knob, control ...................................................................... 1
34 905 0629.4 Screw, cap, 1/4 - 20 x 7/8 hex head .................................. 2
35 905 3440.9 Nut ...................................................................................... 2
36 503 2307.5 Piston rod end .................................................................... 1
37 503 2308.3 Outside tube ....................................................................... 1
38 503 2309.1 Clamp ................................................................................. 1
39 503 2310.5 Piston rod ........................................................................... 1
40 503 2311.3 Cup, leather........................................................................ 1
41 503 2312.1 Washer, cup ....................................................................... 1
42 503 2313.0 Spring ................................................................................. 1
Parts List—Switch and Dash Pot Details (and optional Wet Cutting System)
