777 Segment Bender
Greenlee Textron Inc. / Subsidiary of Textron Inc. 4455 Boeing Dr., Rockford, IL 61109 815-397-7070
2
Table of Contents
Safe Operating Practices......................................................................................3
Description and Purpose ......................................................................................3
Operating Instructions
Set-up...............................................................................................................4
Bending Conduit ..............................................................................................5
Bending Instructions
Glossary of Bending Terms (with illustrations) ................................................6
Laying Out One-Shot 90° Bends .....................................................................7
Laying Out Offset Bends..................................................................................8
Calculating the Center-to-Center Distance .................................................8
Calculating Shrink .......................................................................................9
Laying Out a Segment Bend.................................................................... 10-12
Other Bending Information.............................................................................13
Maintenance
Exploded View and Parts List ........................................................................14
Frame Unit — Parts List ................................................................................15
Ram — Parts List ..................................................................................... 16-17
The symbol above is used to call your attention
to hazards or unsafe practices which could result
in an injury or property damage. The signal word,
defined here, indicates the severity of the hazard.
The message after the signal word provides
information for preventing or avoiding the hazard.
Hazards or unsafe practices which, if not avoided, MAY
result in injury or property damage.
Hazards which, if not avoided, COULD result in severe
injury or death.
Immediate hazards which, if not avoided, WILL result in
severe injury or death.
SAFETY
ALERT
SYMBOL
