EK50ML Battery-powered Crimping Tool
4455 Boeing Drive • Rockford, IL 61109-2988 • USA • 815-397-7070
An ISO 9001 Company • Greenlee Textron Inc. is a subsidiary of Textron Inc.
USA Tel: 800-435-0786
Fax: 800-451-2632
Canada Tel: 800-435-0786
Fax: 800-524-2853
International Tel: +1-815-397-7070
Fax: +1-815-397-9247
www.greenlee.com
Parts List (cont’d)
Key Part No. Description Qty
52068845 Switch board assembly
17 Distance roll ø6 x 3 ................................................................................... 2
18 Plate for mini 10.8V ................................................................................... 1
19 Screw DIN 7985 M3 x 6–4.6-Z zinc plated ............................................... 2
52068846 Cup spring assembly
6 Compression spring .................................................................................. 1
7 Cup spring DIN 2093–18 x 0.5 x 8.2 ......................................................... 7
8 Shim washer DIN 988–13 x 19 x 0.5 ......................................................... 1
32 52068847 Release lever and spacer
52068848 Tool housing (complete) 12 mm jaw
27 Housing assembly, green .......................................................................... 1
52068850 Tool housing (complete) 13 mm jaw
27 Housing assembly, green .......................................................................... 1
Replacement Parts
21 52068569 Flat exible cable 8-pole L 131.5 .............................................................. 1
26 52068582 Programmed circuit board ........................................................................ 1
