Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070
8
EK628LX Battery-powered Crimping Tool
CJ22 Jaw and KA22/KC22-type Die Selection
Note: This tool will provide a cUL and UL classified crimp ONLY when used with the CJ22 jaws
and KA22- or KC22-type dies.
Note: This tool will provide 53 kN (6 tons) of crimping force when used with the CJ22 jaws.
Crimps made on copper cable with Greenlee KC22-type dies and the copper connectors listed here are cUL and UL classied.
Crimps made on copper or aluminum cable with Greenlee KA22-type dies and the dual-rated aluminum connectors listed
here are cUL and UL classied.
Refer to “Connector Selection” for brand names and model numbers of appropriate lugs as well as crimping instructions.
95R7
Dies for Dual-rated Aluminum Connectors
Catalog Number UPC Number Cable Size
KA22-8 06744 8 AWG
KA22-6 06745 6 AWG
KA22-4 06746 4 AWG
KA22-2 06747 2 AWG
KA22-1 06749 1 AWG
KA22-1/0 06750 1/0 AWG
KA22-2/0 06751 2/0 AWG
KA22-3/0 06752 3/0 AWG
KA22-4/0 06753 4/0 AWG
KA22-250 06754 250 kcmil
KA22-300 06755 300 kcmil
KA22-350 06756 350 kcmil
Dies for Copper Connectors
Catalog Number UPC Number Cable Size Color Code
KC22-8 03079 8 AWG Red
KC22-6 03080 6 AWG Blue
KC22-4 03081 4 AWG Gray
KC22-2 03082 2 AWG Brown
KC22-1 03083 1 AWG Green
KC22-1/0 03084 1/0 AWG Pink
KC22-2/0 03085 2/0 AWG Black
KC22-3/0 03086 3/0 AWG Orange
KC22-4/0 03087 4/0 AWG Purple
KC22-250 03088 250 kcmil Yellow
KC22-300 03089 300 kcmil White
KC22-350 03090 350 kcmil Red
KC22-400 03091 400 kcmil Blue
KC22-500 03092 500 kcmil Brown
KC22-600B 03094 600 kcmil Green
Connector Selection
CJ22 Crimping Jaw Range: Copper — 8 AWG to 600 kcmil†; Dual-rated Aluminum — 8 AWG to 350 kcmil
When used with KC22-type dies, this tool is cUL and UL classied for use with the following connector brands:
Connector
Type
Barrel
Type
Anderson Blackburn
®
Burndy ILSCO Panduit T&B
Penn-
Union†
No. of
Crimps*
Copper
Splice
Short VHSS CSP YS-L
s
CT SCSS/SCS 54504-54518 BCU
A
Long VHS CU YS
s
CTL SCL/SCH 54804-54818 BBCU
Copper
Lugs
Short VHCS CTL-2/CTL
YA-2LN/YA-L/YA-2L
YA/YA-L-TC/YA-L-2TC
CSW
CRA/CRB
LCAS/LCA
LCD
54104-54118
54204-54218
BLU
Long VHCL CTL-L/LCN YA-2N
CLN/CLW
CRA-L/CRB-L
CRA-2L/CRB-2L
LCB/LCC
54930BE-54918BE
54850BE-54876BE
BBLU
When used with KA22-type dies, this tool is cUL and UL classied for use with the following connector brands:
Connector Type Barrel Type Anderson Blackburn
®
Burndy ILSCO Panduit** T&B
Penn-
Union
No. of
Crimps*
Dual-rated
Aluminum Splice
— VACS ASP YS-A
AS
ASN
SA 60501-60565 PIK
B
Dual-rated
Aluminum Lugs
— VACL ATL
YA-A
YA-ATN
ACL/ACN
2ACL/2ACN
ALNS/ALNN/ALND
LAA/LAB
60101-60166
60230-60267
BLUA
* Use the number of crimps listed in the last column instead of the number provided with the connector:
A — 8 to 1/0 AWG: 1 crimp B — 8 to 2 AWG: 2 crimps
2/0 AWG to 600 kcmil: 2 crimps 1 to 3/0 AWG: 3 crimps
4/0 AWG to 350 kcmil: 4 crimps
** 6 AWG to 350 kcmil
† 500 kcmil maximum with Penn-Union connectors
s
8 AWG to 350 kcmil with Burndy copper splices
