14
ASSEMBLY INSTRUCTIONS
Fig. 4
2
1
3
INSTALLING THE MULCHING PLUG (See Figure 4)
• To remove the mulching plug, lift the chute cover (1).
• Grasp the handle (2) of the mulching plug and pull the mulching plug out using the handle.
• The mulching plug (3) is inserted on an angle, so it requires some force to remove it.
• The mulching plug must be removed in order to install the grass catcher bag.
• The mulching plug must be re-installed when the grass catcher bag is removed.
