15
English (Original Instructions)
Before use of this product, familiarize yourself with all
operating features and safety rules.
GRASSBOX
The grassbox collects grass clippings and prevents them
from being discharged across your lawn as you mow.
HEIGHT ADJUSTMENT LEVER
The height adjustment lever provides cutting height
adjustments.
MOTOR CONTROL CABLE
The motor control cable, located on the upper handle of
the mower, engages and disengages the motor and blade.
MULCHING PLUG
Your mower is equipped with a mulching plug that covers
the rear discharge opening, which allows the mower blade
■ Operator’s manual
WARNING
If any parts are damaged or missing do not operate this
product until the parts are replaced. Using a product
with damaged or missing parts could result in serious
personal injury.
WARNING
Do not attempt to modify this product or create
accessories not recommended for use with this product.
Any such alteration or modication is misuse and could
result in a hazardous condition leading to possible
serious personal injury.
WARNING
To prevent accidental starting that could cause serious
personal injury, always disconnect from the power
supply when assembling parts.
WARNING
Never operate the mower without the proper safety
devices in place and working. Never operate the mower
with damaged safety devices. Operation of this product
with damaged or missing parts could result in serious
personal injury.
UNFOLDING AND ADJUSTING HANDLE
See gure 2.
■ Pull up and back on the upper handle to raise the
handle into operating position. Make certain the
handles snap into place securely.
■ Secure the lower handle with the quick release
fasteners on both sides.
■ Tighten the upper handle with the quick release
fasteners on both sides.
INSTALLING THE GRASSBOX
See gure 3.
■ Lift the rear discharge door.
■ Lift the grassbox by its handle and place under the
rear door, so that the hooks on the grassbox frame are
seated into the slots in the handle bracket.
■ Release the rear door. When installed correctly, the
hooks on the grassbox will rest securely in the slots on
the handle brackets.
to cut and recut for ner clippings.
ASSEMBLY
UNPACKING
This product requires assembly.
■ Carefully remove the product and any accessories
from the box. Make sure that all items listed in the
packing list are included.
WARNING
Do not use this product if any parts on the packing list are
already assembled to your product when you unpack it.
Parts on this list are not assembled to the product by
the manufacturer and require customer installation. Use
of a product that may have been improperly assembled
could result in serious personal injury.
■ Inspect the product carefully to make sure no breakage
or damage occurred during shipping.
■ Do not discard the packing material until you have
carefully inspected and satisfactorily operated the
product.
■ If any parts are damaged or missing, please call your
Greenworks tools service centre for assistance.
PACKING LIST
■ Lawn mower
■ Grassbox
■ Mulching plug
