KNOW YOUR PRESSURE WASHER
The safe use of this product requires an understanding of the information on the tool and in this
operator’s manual as well as a knowledge of the project you are attempting. Before use of this
product, familiarize yourself with all operating features and safety rules. (See Figure 2.)
DETERGENT TANK
Remove the cap from the detergent tank and add detergent.
GFCI PLUG
The pressure washer is equipped with a GFCI plug to guard against the hazards of ground fault
currents. This plug does not protect against short circuits, overloads, or shocks.
7. Spray wand
8. Gun
ON / OFF SWITCH
This switch turns the pressure washer on and off.
TRIGGER HANDLE
The trigger handle has a gripping surface that provides added control of the spray wand and
helps reduce fatigue.
TRIGGER WITH LOCK-OUT
Pulling the trigger releases a stream of water for high pressure cleaning. The lock-out provides
protection against unauthorized use.
UNPACKING
This product requires assembly.
■ Carefully remove the product and any access detsil smeti lla taht erus ekaM .xob eht morf seiro
in the packing list are included.
5. Detergent tank
3.Gun storage hook
4.Water intake
Fig. 2
6. High pressure
hose
2. On/Off switch
1. Electric cord hook
