18
OPERATION
USING THE SPRAY WAND TRIGGER
(See Figure 8.)
For greater control and safety, keep both hands on the trigger handle at all times.
• Pull back and hold the trigger to operate the pressure washer.
•
W A R N I N G
Do not slide lock-out button when you have the trigger at back position.
W A R N I N G
NEVER change nozzles without engaging the lock-out on the trigger handle and NEVER point the
wand at your face or at others. The quick-connect feature contains small springs that could eject
the nozzle with some force. Failure to heed this may cause personal injury.
USING NOZZLE
(See Figure 9.)
NOTE:
1-Pull back the quick-connect collar
2-Push the nozzle into place
3-Push the collar forward
TO ENGAGE THE LOCK-OUT:
• Push up on the lock-out until it clicks into the slot.
TO DISENGAGE THE LOCK-OUT:
• Push the lock-out down and into its original position. For the most effective cleaning, the spray
nozzle should be between 8 in. and 24 in. from the surface to be cleaned. If the spray is too
close it can damage the cleaning surface.
Fig. 8
Fig. 9
3
Spray wand
2
1
Nozzle
Slot
Trigger
Lock out
