WARNING
Do not touch the cut-off blade.
1. Remove the screws from the trimmer head with a
Phillips head screwdriver (not included).
2. Put the guard onto the trimmer head.
3. Align the screw holes on the guard with the screw
holes on the trimmer head.
4. Tighten the screws.
4.3 ASSEMBLE THE SHAFT
Figure 3 - 5.
1. Loosen the screw on the coupler.
2. Push in the release button on the lower shaft.
3. Align the release button with the positioning hole
and slide the two shafts.
4. Turn the lower shaft until the button locks into the
positioning hole.
5. Tighten the screw with the hex wrench.
4.4 ATTACH THE AUXILIARY HANDLE
Figure 6.
1. Loosen the central knob.
2. Remove the cap and the lower support.
NOTE
Do not miss the spring in the support.
3. Put the auxiliary handle in the lower support.
4. Put the cap to the lower support.
5. Put the entire block in its housing on the shaft.
6. Set the auxiliary handle in the comfortable
position.
7. Lock the auxiliary handle with the central knob.
4.5 USE THE SHOULDER STRAP
Figure 7.
1. Attach the carabiner to the carrying ring on the
pole.
2. Put on the shoulder strap.
3. Adjust the length of the strap so that the
carabiner is about the width of a hand below your
right hip.
4.6 INSTALL THE BATTERY PACK
Figure 8.
WARNING
• If the battery pack or charger is damaged, replace
the battery pack or the charger.
• Stop the machine and wait until the motor stops
before you install or remove the battery pack.
• Read, understand, and follow the instructions in
the battery and charger manual.
1. Align the lift ribs on the battery pack with the
grooves in the battery compartment.
2. Push the battery pack into the battery
compartment until the battery pack locks into
place.
3. When you hear a click, the battery pack is
installed.
4.7 REMOVE THE BATTERY PACK
Figure 8.
1. Push and hold the battery release button.
2. Remove the battery pack from the machine.
5 OPERATION
IMPORTANT
Before you operate the machine, read and
understand the safety regulations and the operation
instructions.
WARNING
Be careful when you operate the machine.
5.1 ON/OFF BUTTON
Push this button to connect and disconnect the
electrical circuit of the machine.
Two green lights on (G): the electrical circuit of the
machine is on (ON). The machine prepares to operate.
NOTE
If you do not use the machine for more than 1
minute, the machine stops.
Lights off: the electrical circuit is off (OFF).
IMPORTANT
Do not keep your finger on the button when you
move the machine to prevent accidental start.
5
English
EN
