EN - 19
OPERATION
W A R N I N G
NEVER change spray tips without engaging the lock-out on the trigger handle and NEVER point the
wand at your face or at others. The quick-connect feature contains small springs that could eject the
spray tip with some force. Failure to heed this may cause personal injury.
TO DISCONNECT A SPRAY TIP FROM THE SPRAY WAND ONCE THE CLEANING JOB
IS COMPLETE:
■ Turn off the pressure washer and shut off the water supply. Pull trigger to release water pressure.
■ Remove the spray tip by placing hand over spray then pulling back the quick-connect collar. Place
spray tip in the tip storage area on the units folding handle.
USING THE SPRAY WAND TRIGGER (See Figure 11.)
For greater control and safety, keep both hands on the trigger handle at all times.
■ Pull back and hold the trigger to operate the pressure washer.
■ Release the trigger to stop the flow of water through the tip.
TO ENGAGE THE LOCK-OUT:
■ Push up on the lock-out until it clicks into the slot.
TO DISENGAGE THE LOCK-OUT:
■ Push the lock-out down and into its original position.
Slot
Fig. 11
Trigger
Lock out
