GreenWorks ST40B05 - Replace the Cutting Line

6. Extend the cutting line to release it from the guide
slot in the spool.
5
7. Push the tabs and install the spool cover onto the
spool housing.
8. Push the spool cover until it clicks into position.
CLICK
10.4 REPLACE THE CUTTING LINE
NOTE
Remove the remaining cutting line on the spool.
NOTE
Use only with the nylon cutting line of .065" (1.65 mm)
diameter.
1. Cut a piece of cutting line approximately 3m long.
2. Bend one end of the line 1/4 of an inch (6.35mm) .
3. Insert the line into the anchor hole of the spool.
4. Wind the cutting line around the spool tightly in the
indicated direction.
5. Put the cutting line in the guide slot.
12
