8.4 CUTTING TIPS
• Tilt the machine toward the area to be cut. Use the tip of
the cutting line to cut grass.
• Move the machine from right to left to prevent thrown
debris toward the operator.
• Do not cut in the dangerous area.
• Do not force the trimmer head into uncut grass.
• Wire and picket fences cause cutting line wear and
breakage. Stone and brick walls, curbs, and wood can
wear the cutting line quickly.
'$1*(5
$5($
%(67&877,1*
$5($
',5(&7,212)
527$7,21
8.5 ADJUST THE LENGTH OF THE
CUTTING LINE
NOTE
The machine has an auto-feed head. It will damage the
machine if you hit the head to try to advance the line.
NOTE
If the cutting line does not automatically advance, it can be
tangled or empty.
1. When the machine is on, release the trigger.
2. Wait two seconds, push the trigger again.
3. Resume trimming.
NOTE
The line will extend approximately 0.4 in. with each stop
and start of the switch trigger until the line reaches the cut-
off blade and the cut-off blade cuts the excess length.
8.6 ADJUST THE LENGTH OF THE
CUTTING LINE MANUALLY
1. Stop the machine.
2. Push the line release button and pull on cutting line to
manually advance the cutting line.
3. After you extend new cutting line, always return the
machine to its normal position before you start it again.
8.7 ADJUST THE CUTTING
DIAMETER
NOTE
The machine is set at a 12 in. (305 mm) cutting diameter.
You can adjust to a 10 in. (254 mm) cutting diameter.
Set the cutting diameter to 10 in. (254 mm) for greater
runtime and 12 in. (305 mm)for a larger cutting area.
1. Remove the battery pack.
2. Remove the blade screws from the cut-off blade (15).
3. Turn the cut-off blade 180°.
4. Tighten the blade screws.
8.8 CHANGE TO THE EDGING MODE
NOTE
The machine can be used in combination with the edge
guide for edging sidewalks and walkways.
1. Stop the machine and flip down the edge guide from
stored position.
2. Pull the edging coupler and turn the trimmer head 180
degrees until the trimmer head locks into position.
9
