H60.0.13.6C-17 Operating Manual GMH 3851 Page 16 of 22
_____________________________________________________ _____________________________________________________________________________
13 Specification
Measuring Channel 1 Channel 2
Principle Resistive material-moisture-measuring Temperature-measuring thermocouple type K
matching DIN EN 13183-2: 2002 or internal temperature-measuring
or according VDI 4206 sheet 4
Char. curve 466 different kinds of wood matching DIN EN 60584-1: 1996, ITS90
28 different building materials
4 individually programmable material curves
Probe connection BNC Plug floating connector for mini-blade-terminal
Meas. range 0,0...100,0 % u moisture content thermocouple:
-40,0... +200,0 °C / -40,0... +392,0 °F
(depending on characteristic curve) int. temp.-Meas:
-30,0...+75,0 °C / -22,0...+167,0 °F
equal to approx. 3kOhm ... 2TerraOhm
Spec. meas. range Wood: 8 … 40 % u Wood temperature 0 … 40 °C (no frozen wood!)
Resolution 0,1 % moisture content 0,1 °C / 0,1 °F
Evaluation Evaluation of the material condition in
9 steps from DRY to WET
Accuracy Device ±1Digit (at nominal-temperature)
without probe Wood: ±0,2 % moisture content Type K: ± 0.5% m.v. ± 0.3 °C
(deviation from characteristic curve, int. t.-measuring: ± 0,3 °C (is type K reference
range 8..40 % u) junction)
building mat.: ±0,2 % moisture content
(dev. from char. curve, range depending
on char. curve)
overall accuracy depending on used measuring equipment, measured material and the correct execution.
Temperature drift < 0,005 % moisture content per 1 K 0,01 % per 1 K
Nominal temperature 25°C
Ambient condition Temperature -25 ... +50 °C / -13 ... +122 °F (frozen material cannot be measured)
Relative humidity 0 ... 95 %RH (non condensing)
Storage temperature -25 ... +70 °C / -13 ... +158 °F
Output: 3.5 mm audio plug, stereo (max. permissible length of connection cable < 3 m)
output selectable as:
serial interface: via optically isolated interface adapter GRS 3100, GRS 3105 or USB 3100 N (p.r.t.
accessories) directly connectable to RS232- or USB-interfaces.
analog output: 0..1 V, freely scalable (resolution 13 bit, accuracy 0.05 % at nom. temp., cap. load <1 nF)
Logger: 2 Functions: individual value logger (“Func–Stor“) and cyclic logger (“Func–CYCL“)
Memory: Stor: 99 data sets; CYCL: 10000 data sets
Cycle time CYCL: 0:30...60:00 (minutes:seconds, min 1 s, max 1 h)
Real time clock: Integrated clock with date and year
Power Supply 9V-Battery (included) as well as additional d.c. connector (diameter of internal pin 1.9 mm) for
external 10.5-12 V direct voltage supply. (suitable power supply: GNG10/3000)
Power Consumption output off approx. 2.5 mA
output serial interface: approx. 2.7 mA
analog output: approx. 3.0 mA
cyclic logger sleeping state with output deactivated: < 0.1 mA
cyclic logger sleeping state with activated serial interface: < 0.3 mA
Display Two 4 digits LCD’s (12.4 mm high and 7 mm high) for material moisture temperature or
characteristic curve, hold function, etc. as well as additional pointing arrows.
Pushbuttons 6 membrane keys for on/off switch, menu operation, characteristic curve, hold-function etc.
Housing Dimension: 142 x 71 x 26 mm (L x B x D)
impact resistant ABS, membrane keyboard, transparent panel, integrated pop-up-clip for table
top or suspended use
Weight approx. 155 g
Hold Function Press button to store current value.
Automatic-Off-Function Device will be automatically switched off if no key is pressed/no interface communication
takes place for the time of the power-off delay. The power-off delay can be set to values
between 1 and 120 min.; it can be completely deactivated.
