H60.0.13.6C-17 Operating Manual GMH 3851 Page 9 of 22
_____________________________________________________ _____________________________________________________________________________
5.7.3 Measuring
Split the log:
Use an suitable axe for splitting. Fast working splitting machines can produce heat which may falsify the
measuring.
Preparation of core temperature measuring of log:
Drive in the impact electrode, put temperature probe into the generated hole.
Three measuring values have to be taken at the freshly split surface,
2 measuring spots should have 5 cm distance
from cut side, the third should be placed in the
center.
Drive in the needles sufficiently deep( > 5mm) and
across the fibre direction
Measuring procedure:
Measuring value 1 will be
automatically taken
Instrument is ready for
next step
Measuring value 2 will be
automatically taken
Instrument is ready for
next step
Measuring value 3 will be
automatically taken
Average out of the 3 will
be displayed
Return to continuous
measuring display
