Grid Tie 500W - Technical Parameters

Technical Parameters:
Suitable for 60 cells solar panel which Vmp is 26-30V and Voc is 34-38V.
Rated Power 500W
Compatible with Solar
Panels
500-600W 60 cells
DC Input Range 20-40VDC
MPPT Voltage 24-33VDC
DC MAX. Current 25A
AC Output 120VAC/230VAC(90-260VAC)
Frequency 50Hz/60Hz(Auto control)
Power Factor >97.5%
THD <5%
Phase Shift <2%
Efficiency 120VAC(90-140VAC)
Peak Efficiency 88%
Stable Efficiency 86%
Efficiency 230VAC(190-260VAC)
Peak Efficiency 89%
Stable Efficiency 87%
Protection
Islanding; Short-circuit; Converse Connection; Low Voltage;
Over Voltage; Over Temperature Protection
Working Temperature
-25℃-65℃
Working Humidity 0%~90%RH non-condensing
Waterproof Indoor design
Show Luminous Diode(LED)
Cooling Fan
Stand-by Power
＜1W
EMC EN61000-6-3:2007 EN61000-6-1:2007
Grid Disturbance EN 50178+EN 62109-1+VDE0126-1-12
Grid Detection DIN VDE 1026 UL1741
Certificate
CE
