Grid Tie 500W - Installation Guide

Packing Specification
Packing Accessory Microinverter, AC Cord, User Manual(Warranty Card)
Mechanical Size 21 x 16.5 x 5.3CM
Net Weight/PCS 1.3KGS/PCS
Inner Box (L x W x H)
31 x 21 x 11.5CM
Carton(L x W x H)
42 x 31.5 x 35.5CM, 6PCS/CTN, 8/11KGS
1. Diagrammatize DC input and AC output terminals,
2. Attach the Smart Microinverter to the racking or fix onto the wall,
3. Properly connect the positive and negative of solar panel and Smart
Microinverter,
Installation
5/13
