8
3
1/4"x3/8" Phillips Head Screw
Q
TY. 4
In
s
t
a
l
l
T
a
n
k
H
o
l
ders and Casters
Install Tank Holders to each side of Cart Frame. (Tighten se-curely using 4 of 1/4"x3/8" Phillips Head Screws)
Install Casters to each Cart Leg.(Install casters with the wrench provided).
Casters Installation Code
The installation shall be made with a connector (installed on this grill) with the Standard for
Connectors for Mova
ble Gas Appliances, ANSI Z21.69-CSA6.16.
4
Install Lid Handles to Left and Right Lid.
(Tighten securely using 4 of 3/16"x3/8" Phillips Head Screws )
Install Bowl Handles to each Bowl Support Bracket.
(Tighten secur
ely using 12 of 1/4"x1/2" Phillips Head Screws)
Install Handles
3/16"x3/8"
Phillips Head Screw
Q
TY. 4
1/4"x1/2" Phillips Head Screw
QTY. 12
A
B
A
B
To Next Page
