COMPRESSOR PARTS LIST - PUMP
REF NO. DESCRIPTION QTY. PART#
1 Head Bolt 4 GRFC12
2 Head 1 GRFC32
3 Intake filter 1 GRFC58
4 Head Gasket 1 GRFC34
5 Valve Plate 2 GRFC38
6 Gasket 1 GRFC35
7 Reed Valve 2 GRFC39
8 Valve Plate Gasket 1 GRFC37
9 Cylinder 1 GRFC47
10 Bolt 2 GRFC17
11 Gasket 1 GRFC44
12 Comp. Piston Assy 1 GRFC67
Ring Set 1 GRFC56
Piston 1 GRFC33
Piston Pin 1 GRFC40
Snap Rings 2 GRFC21
Connecting Rod 1 GRFC45
13 Capacitor 1 GRFC2
14 Capacitor Cover 1 GRFC41
15 Dipstick 1 GRFC9
16 Screw 4 GRFC18
17 Crankcase Cover 1 GRFC22
18 Gasket 1 GRFC4
19 Oil Drain 1 GRFC19
20 Gasket 1 GRFC43
21 Motor Housing 1 GRFC42
22 Nut 2 GRFC13
23 16 AMP Manual Reset 1 GRFC1
24 Crankshaft 1 GRFC36
25 Bearing 1 GRFC25
26 Seal 1 GRFC3
27 Rotor 1 GRFC46
28 Stator 1 GRFC64
To Next Page
