14
COMPRESSOR PARTS LIST - TANK
REF NO. DESCRIPTION QTY. PART#
1 Tank Assembly 1 GRFC50
2 Drain cock 2 GRFC24
3 Handle Grip 1 GRFC49
4 Mounting Plate 1 GRFC52
5 Screw 3 GRFC10
6 Nut 8 GRFC13
7 Vibration Damper 4 GRFC53
8 Screw 4 GRFC20
9 Nut for Rubber Feet 4 GRFC14
10 Rubber Foot 4 GRFC23
11 Check Valve 1 GRFC63
12 Nylon Tubing 1 GRFC27
13 Discharge Tube 1 GRFC55
14 Discharge Tee 1 GRFC54
15 Bleeder Valve 1 GRFC8
16 Nipple 1 GRFC5
17 Safety Valve 1 GRFC28
18 Cord w/Plug 1 GRFC51
19 Pressure Switch 1 GRFC60
Pressure Switch Cover GRFC66
20 Tank Gauge 1 GRFC62
21 Nipple 1 GRFC5
22 Regulator 1 GRFC59
23 Screw TE 4 GRFC11
24 Line Gauge 1 GRFC61
25 Compression Nut 2 GRFC7
26 Compression Ring 2 GRFC6
Compete Motor/Pump Assembly 1 GRFC65
