7.3 LED Fault Indicator
In the instance of a fault remains, it is recommended that you:
1. Unplug the charging Connector from your EV
2. Turn off the power to the Charging Station by switching the upstream circuit breaker to
the “OFF” position
3. With the circuit breaker in the “OFF” position, wait 1-2 minutes and then switch the
upstream circuit breaker back to the “ON” position
4. Confirm the Fault light is no longer present. If the Fault light remains, please contact
United Chargers.
# of Flashes Error Description Primary Secondary
1 Lost ground - AC Solid Red Modulated Red
2 GFCI High Solid Red Modulated Red
3 Relay is stuck Solid Red Modulated Red
4 GFCI Low Solid Red Modulated Red
5 High temperature of
the module
Solid Red Modulated Red
6 High temperature of
the relay-
Solid Red Modulated Red
7 Pilot state is Status E Solid Red Modulated Red
8 x Pilot state is Status
F
Solid Red Modulated Red
9 Diode error Solid Red Modulated Red
11 No connection with
secondary module
Solid Red N/A
12 Application error Solid Red Modulated Red
7.4 Reset Board
The number of Red Flashes indicates the charger error:
