Grizzly G0458 Owner's Manual

-42-
Model G0458 (Mfg. Since 5/11)
REF PART # DESCRIPTION REF PART # DESCRIPTION
200 PSB33M CAP SCREW M5-.8 X 12 247 P0458247 ROD
201 P0458201 CHIP DEFLECTOR PLATE 248 PSB79M CAP SCREW M5-.8 X 35
202 PFH43M FLAT HD SCR M6-1 X 10 249 P0458249 SPACER
203 PFH07M FLAT HD SCR M5-.8 X 10 250 P0458250 PIN
204 PSS24M SET SCREW M5-.8 X 25 251 PLW06M LOCK WASHER 10MM
205 PN06M HEX NUT M5-.8 253 P0458253 PULLEY COVER
206 P0458206 BUSHING 254 P0458254 PULLEY SHAFT
207 PSB142M CAP SCREW M10-1.5 X 10 255 P0458255 PULLEY
208 PSB64M CAP SCREW M10-1.5 X 25 256 PB04M HEX BOLT M6-1 X 10
209 PSB33M CAP SCREW M5-.8 X 12 257 PB04M HEX BOLT M6-1 X 10
210 P0458210 PRESSURE PLATE 258 PB04M HEX BOLT M6-1 X 10
211 P0458211 LINK 259 PW03M FLAT WASHER 6MM
212 PSB04M CAP SCREW M6-1 X 10 260 PW03M FLAT WASHER 6MM
213 P0458213 SPRING SHEET 261 P0458261 BEARING 6002ZZ
214 P0458214 HEADCASTING 262 PW21M FLAT WASHER 32MM
215 P0502058 BEARING 6205ZZ 263 P0458263 STAND
216 P0458216 BEARING COVER 264 P0458264 FRONT SUPPORTING PLATE
217 PSB26M CAP SCREW M6-1 X 12 265 P0458265 SIDE SUPPORTING PLATE
218 P0458218 COLLAR 266 P0458266 FRONT PLATE
219 PN06M HEX NUT M5-.8 267 P0458267 SIDE PLATE
220 PSS34M SET SCREW M5-.8 X 16 268 PCB06M CARRIAGE BOLT M8-1.25 X 16
221 PW02M FLAT WASHER 5MM 269 PFN01M FLANGE NUT M8-1.25
222 P0458222 DUST HOSE CLAMP 270 PB09M HEX BOLT M8-1.25 X 20
223 P0458223 SWITCH RESET 271 PN03M HEX NUT M8-1.25
224 PLW04M LOCK WASHER 8MM 272 PW01M FLAT WASHER 8MM
225 P0458225 OPEN END WRENCH 8/12MM 273 P0458273 DUST BAG
226 PS19M PHLP HD SCR M5-.8 X 6 274 PW02M FLAT WASHER 5MM
227 PTLW02M EXT TOOTH WASHER 5MM 275 P0458275 G0458 LABEL
228 P0458228 SPACER 276 P0458276 GRIZZLY LOGO
229 PSB33M CAP SCREW M5-.8 X 12 277 P0458277 MACHINE ID LABEL
230 PW02M FLAT WASHER 5MM 278 PLABEL-11 SAFETY GLASSES LABEL
231 PS05M PHLP HD SCR M5-.8 X 8 279 PLABEL-12 READ MANUAL LABEL
232 P0458232 STRAIN RELIEF 280 PLABEL-32 DUST MASK LABEL
233 P0458233 POWER CORD 281 PLABEL-14 ELECTRICITY LABEL
234 P0458234 COMPRESSION SPRING 282 PS98M PHLP HD SCR M3-.5 X 16
235 P0458235 PLATE 283 PN07M HEX NUT M3-.5
236 PW03M FLAT WASHER 6MM 284 P0458284 CONNECTING CORD
237 PRP02M ROLL PIN 3 X 16 285 PW02M FLAT WASHER 5MM
238 PW02M FLAT WASHER 5MM 286 PB112M HEX BOLT M5-.8 X 12
239 PSB33M CAP SCREW M5-.8 X 12 287 PSS02M SET SCREW M6-1 X 6
241 P0458241 ROD 288 P0458288 LOCK NUT 5/8-8
242 PSB33M CAP SCREW M5-.8 X 12 290 P0458290 BUSHING
243 P0458243 PLATE 295 P0458295 WAVE WASHER 40MM
244 PW02M FLAT WASHER 5MM 297 P0458297 SPRING RETAINER
246 PN06M HEX NUT M5-.8 298 PCAP50M CAP SCREW M5-.8 X 10
G0458 Parts List
Safety labels help reduce the risk of serious injury caused by machine hazards. If any label comes
off or becomes unreadable, the owner of this machine MUST replace it in the original location
before resuming operations. For replacements, contact (800) 523-4777 or www.grizzly.com.
