G0459 12" Drum Sander
-11-
Inventory
After all the parts have been removed from the
two boxes, you should have the following items:
Box 1: (Figure
3) Qty
A. Drum Sander ..............................................
1
B.
Crank Handle ............................................. 1
C.
2
1
⁄2" Dust Port ............................................. 1
D. 3mm Hex Wrench ...................................... 1
Figure 3. G0459 Inventory.
In the event that any nonproprietary parts are
missing (e.g. a nut or a washer), we would be
glad to replace them, or for the sake of expedi
-
ency, replacements can be obtained at your local
hardware store.
Figure 4. Minimum working clearances.
Floor Load
Refer to the Machine Data Sheet for the weight
and footprint specifications of your machine.
Some
workbenches may require additional rein-
forcement to support both the machine and the
workpiece
.
Working Clearances
Consider existing and anticipated needs, size of
material to be processed through each machine,
and space for auxiliary stands, work tables or
other machinery when establishing a location for
your new machine. See Figure
4 for the minimum
working clearances.
Unsupervised children and
visitors inside your shop
could cause serious per
-
sonal injury to themselves.
Lock all entrances to the
shop when you are away and
DO NOT allow unsupervised
children or visitors in your
shop at any time!
Site Considerations
24"
26.5"
C
B
A
D
