REF PART # DESCRIPTION REF PART # DESCRIPTION
201 P0502201 CLAMP GATE 216 P0502216 YOKE PIN 8 x 22
202 P0502202 MOUNTING BRACKET 217 PEC015M E-CLIP 8MM
203 P0502203 ACTUATOR BRACKET 218 P0502218 PEDAL ASSEMBLY
204 PCAP01M CAP SCREW M6-1 X 16 219 PCAP01M CAP SCREW M6-1 X 16
205 P0502205 HINGE 220 PB07M HEX BOLT M8-1.25 X 25
206 P0502206 ACTUATOR CYLINDER 221 PLW04M LOCK WASHER 8MM
207 P0502207 CYLINDER YOKE 222 P0502222 BRASS FITTING KIT
208 P0502208 REGULATOR VALVE 223 P0502223 T-FITTING 2.5MM
209 PCAP05M CAP SCREW M8-1.25 X 50 223-1 P0502223-1 T-FITTING 4MM
210 PW01M FLAT WASHER 8MM 224 P0502224 AIR HOSE 4 X 6MM
211 PN03M HEX NUT M8-1.25 224-1 P0502224-1 AIR HOSE 2.5 X 4MM
212 PFH06M FLAT HD SCR M6-1 X 20 225 P0502225 START BUTTON ASSEMBLY
213 PW03M FLAT WASHER 6MM 226 P0502226 CONTROL VALVE UNIT
214 PLW03M LOCK WASHER 6MM 227 P0502227 PHLP HD SCR M4-.7 X 55
215 PN01M HEX NUT M6-1 228 PN04M HEX NUT M4-.7
