Grizzly G0513 Parts List

G0513/G0514 Heavy-Duty Bandsaw -45-
REF PART # DESCRIPTION
114 PS17M PHLP HD SCR M4-0.7 X 6
115 P0513115 GEAR PLATE
116 P0513116 NYLON NUT M8-1.25
117 PS17M PHLP HD SCR M4-0.7 X 6
118 P0513118 LOCK HANDLE
119 PW05M FLAT WASHER 4MM
120 P0513120 POINTER
121 P0513121 TRUNNION PLATE
122 PLW04M LOCK WASHER 8MM
123 PB03M HEX BOLT M8-1.25 X 16
124 PCB23M CARRIAGE BOLT M8-1.25 X 80
125 P0513125 FENCE ASSEMBLY W/RAILS
126 P0513126 TABLE 17" X 17"
127 P0513127 TABLE INSERT
128 P0513128 TABLE PIN
129 PSB85M CAP SCREW M6-1.0 X 6
130 P0513130 LEFT COVER
131 PTS001M THUMB SCREW M6-1 X 16
132 P0513132 LOWER BLADE GUIDE SUPPORT
133 P0513133 GUIDE RING
134 P0513134 LOWER ADJUST SHAFT
135 P0513135 RIGHT COVER
136 PSB50M CAP SCREW M5-0.8 X 10
137 PW02M FLAT WASHER 5MM
138 P0513138 PROTECTIVE COVER
139 PSB72M CAP SCREW M10-1.5 X 30
140 P0513140 STEP SCREW
141 P0513141 FLAT WASHER
142 P0513142 SLIDING PLATE
143 PR05M EXT RETAINING RING 15MM
144 P6202 BEARING 6202
145 P0513145 UPPER BLADE GUIDE SUPPORT
146 P0513133 GUIDE RING
147 PTS001M THUMB SCREW M6-1.0 X 16
148 PCB10M CARRIAGE BOLT M8-1.25 X 85
149 PSB28M CAP SCREW M6-1.0 X 15
150 P0513150 ADJUST BAR
151 P0513151 UPPER SPACING SLEEVE
152 PSB02M CAP SCREW M6-1.0 X 20
153 P0513153 UPPER GUIDE SUPPORT BLOCK
REF PART # DESCRIPTION
154 PS38M PHLP HD SCR M4-0.7 X 10
155 PN04M HEX NUT M4-0.7
156 P0513156 RACK
157 P0513157 UPPER GUIDE HOSE
158 P0513158 HANDWHEEL
159 PSB02M CAP SCREW M6-1.0 X 20
160 P0513160 LOCATE BUSHING
161 P0513161 BUSHING
162 PSB14M CAP SCREW M8-1.25 X 20
163 PLW04M LOCK WASHER 8MM
164 P0513164 GUIDE BRACKET
165 P0513165 WORM CYLINDER
166 P0513166 FIXED PLATE
167 P0513167 GEAR
168 P0513168 FIXED BOLT
169 P0513169 COVER
170 PSB11M CAP SCREW M8-1.25 X 16
171 PS07M PHLP HD SCR M4-0.7 X 8
172 PSS11M SET SCREW M6-1.0 X 16
173 P0513173 MITER GAUGE ASSY
173-1 P0513173-1 GUIDE BAR
173-2 P0513173-2 GUIDE
173-3 P0513173-3 POINTER
173-4 P0513173-4 NYLON WASHER
1
⁄4"
173-5 P0513173-5 HANDLE
1
⁄4"
173-6 P0513173-6 MITER GAUGE BODY
173-7 P0513173-7 SHAFT
173-8 PS37M PHLP HD SCR M6-1.0 X 6
173-9 PFS01M
FLANGE SCREW M5-0.8 X 8
174 P0513174 BRUSH
175 PSB02M CAP SCREW M6-1.0 X 20
176 P0513176 BUSHING
177 P0513177 MACHINE WARNING/ID
178 PLABEL-14 ELECTRICITY WARNING
179 PLABEL-11 SAFETY GLASSES WARNING
180 PLABEL-12 READ MANUAL WARNING
181 PLABEL-19 BLADE TOUCH WARNING
182 PLABEL-20 DOOR CLOSE WARNING
183 PLABEL-18 UNPLUG WARNING
184 G8588 CAST LOGO
G0513
