Grizzly G0581 User Manual

H2933, H2934, G0447, & G0581 Update
(Mfd. Since 1/14)
-3-
Electrical Parts List
Replaces Page 73
REF PART # DESCRIPTION REF PART # DESCRIPTION
101 PH29338101 ELECTRICAL CONTROL BOX (H2933) 115 PH29338115 CONTACTOR SCHN LC1D09 220V
101 PH29348101
ELECTRICAL CONTROL BOX (G0447/H2934) 115-1 PH29348115-1 CONTACTOR SCHN LC1D25 220V
101 P05818101
ELECTRICAL CONTROL BOX (G0581) 116V2 PH29348116V2 GROUND TERMINAL V2.03.10 (G0447/H2934)
102 PH29338102 HINGE 116V2 P05818116V2 GROUND TERMINAL V2.03.10 (G0581)
103 PH29348103
DOOR (G0447/H2934) 116V2 PH29338116V2 GROUND TERMINAL V2.03.10 (H2933)
103 P05818103
DOOR (G0581) 117 PS51M PHLP HD SCR M4-.7 X 30
103 PH29338103 DOOR (H2933) 118V2 PH29338118V2 TERMINAL PLATE V2.03.10
104 PH29338104
BASE PLATE (H2933) 119 PW06 FLAT WASHER 1/4
104 PH29348104
BASE PLATE (G0447/H2934) 120 PLW02 LOCK WASHER 1/4
104 P05818104 BASE PLATE (G0581) 121 PB19 HEX BOLT 1/4-20 X 1/2
105 PN05
HEX NUT 1/4-20 122 PH29338122 PU CONNECTOR 1/2"
106 PLW02
LOCK WASHER 1/4 123 PH29338123 PU CONNECTOR 3/4"
107 PH29338107 CONTROL PANEL 124 PH29338124 CABLE CONNECTOR 1"
108 PS07M
PHLP HD SCR M4-.7 X 8 126A PH29338126A DIGITAL AMP METER N/S
109 PH29338109 CURRENT SENSOR 127 PH29348127 START DELAY LADS2 (G0447/H2934)
110V2 PH29338110V2 TRANSFORMER V2.03.10 127V2 P05818127V2 START DELAY LSD V2.03.10 (G0581)
111 PH29348111
CONTACTOR SCHN LC1D38 220V
(G0447/G0581/H2934)
128 PH29338128
START SWITCH
111V2 PH29338111V2
CONTACTOR SCHN LC1D40A 220V V2.04.13
(H2933)
129 PH29338129
STOP SWITCH
112 PH29348112
OL RELAY SCHN LR3D32 23-32A
(G0447/H2934)
130 PH29338130
POWER INDICATION LIGHT
112 P05818112 OL RELAY SCHN LR3D35 30-38A (G0581) 131 PH29338131 EMERCENGY STOP SWITCH
112V3 P0539012V3
OL RELAY SCHN LRD340 30-40A V3.04.13
(H2933)
132 PH29338132
WIRE COLUMN (G0447/H2933/H2934)
113V2 PH29338113V2
FUSE 4A V2.03.10 132 P05818132 WIRE COLUMN (G0581)
114 PH29338114 OL RELAY SCHN LR3D08 2.5-4A
(G0447/H2933/H2934)
133 PH29338133 COMPUTER
114 P05818114
OL RELAY SCHN LR3D12 5.5-8A (G0581) 139 PH29338139 CONTACTOR SCHN LC1D09 220V W/LOCK
H2933 440V Conversion Kit
139V2 PH29339139V2 440V CONVERSION KIT
134V2 PH29338134V2 OL RELAY SCHN LR3D325 17-25A V2.04.13
135 PH29338135 OL RELAY SCHN LR3D07 1.6-2.5A
H2934 440V Conversion Kit
139 PH29349139 440V CONVERSION KIT
134 PH29348134 OL RELAY SCHN LR3D21 12-18A
135 PH29338135 OL RELAY SCHN LR3D07 1.6-2.5A
G0447 440V Conversion Kit
139 PH29349139 440V CONVERSION KIT
134 PH29348134 OL RELAY SCHN LR3D21 12-18A
135 PH29338135 OL RELAY SCHN LR3D07 1.6-2.5A
G0581 440V Conversion Kit
139 P05819139 440V CONVERSION KIT
134 PH29348134 OL RELAY SCHN LR3D21 12-18A
135 PH29338114 OL RELAY SCHN LR3D08 2.5-4A
