Grizzly G0581 User Manual

H2933/H2934/G0447/G0581 Wide Belt Sander -67-
Sanding Drum and Platen Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
101 PH29335101
BEARING HOUSING
304 PH29335304
GRAPHITE 25" x 3.54" (H2933)
102 PH29335102
RUBBER ROLLER (H2933)
102 PH29345102
RUBBER ROLLER (H2934/G0447)
102 P05815102
RUBBER ROLLER (G0581)
304 P05815304
GRAPHITE 44" x 3.54" (G0581)
103 PH29335103
FASTENING TUBE
305 PH29335305
PHLP HD SCR 10-24 X 1/2
104 PH29335104
BEARING UCC206
105 PH29335105
PULLEY
106 PH29335106
CAP SCREW 5/16-18 X 1-1/4
107 PH29335107
KEY 5/16 X 5/16 X 1 3/16
108 PH29335108
LOCK WASHER 5/16
109 PH29335109
BALL BEARING 6205ZZ
110 PH29335110
LOCK WASHER 1/2
307 PH29335307
GRAPHITE BRACKET BASE
111 PH29335111
CAP SCREW 1/2-12 X 1-1/2
112 PH29335112
CAP SCREW 1/4-20 X 1/2
113 PH29335113
BEARING CAP
114 PH29335114
GREASE FITTING W/CAP
115 PH29335115
GREASE FITTING W/CAP
116 PH29335116
PLUG
117 PH29335117
PULLEY COVER
309 PH29335309
LOCK COLLAR
118 PH29335118
PHLP HD SCR 1/4-20 X 1/2
310 PH29335310
SET SCREW 1/4-20 X 3/8
119 PH29335119
SPANNER NUT
311 PH29335311
KEY 1/4-20 X 25
120 PH29335120 PHLP HD SCR 1/4-20 X 3/8 312 PH29335312
COMPRESSION SPRING
201 PH29335201
BEARING HOUSING
313 PH29335313
HOUSING
202 PH29335202
STEEL ROLLER (H2933)
314 PH29335314
GRAPHITE BRACKET SHAFT
202 PH29345202
STEEL ROLLER (H2934/G0447)
315 PH29335315
CAP SCREW 3/8-16 X 3/4
202 P05815202
STEEL ROLLER (G0581)
316 PH29335316
FLAT WASHER 3/8
203 PH29335203
SPECIAL SET SCREW M6-.75 X 6
317 PH29335317
FLAT WASHER 3/8
204 PH29335204
BEARING UCC205
318 PH29335318
HANDLE
205 PH29335205
HANDLE
319 PH29335319
SET SCREW 5/16-18 X 1/2
206 PH29335206
SPECIAL SCREW
320 PH29335320
ADJUSTMENT RING
211 PH29335211
BEARING BRACKET PAD (H2933)
321 PH29335321
HEX BOLT 5/16-18 X 1
322 PH29335322
FLAT WASHER 5/16
323 PH29335323
HANDLE
401 PH29335401
BEARING HOUSING
402 PH29335402
RUBBER ROLLER (H2933)
402 PH29345402
RUBBER ROLLER (H2934/G0447)
402 P05815402
RUBBER ROLLER (G0581)
403 PH29335403
FASTENING TUBE
405 PH29335405
PULLEY
406 PH29335406
CAP SCREW 5/16-18 X 1-1/4
407 PH29335407
BEARING HOUSING
408 PH29335408
BEARING BRACKET PAD
409 PH29335409
BALL BEARING 6206ZZ
303 PH29335303
25" FELT PLATEN PAD (H2933)
410 PH29335410
SPANNER CAP
411 PH29335411
BEARING CAP
417 PH29335417
PULLEY COVER
303 P05815303
44" FELT PLATEN PAD (G0581)
301 PH29335301 25" GRAPHITE BRACKET MALE
(H2933)
37-1/2" GRAPHITE BRACKET MALE
(H2934/G0447)
PH29345301301
P05815302302
301 P05815301 44" GRAPHITE BRACKET MALE
(G0581)
25" GRAPHITE BRACKET FEMALE
(H2933)
PH29335302302
37-1/2" FELT PLATEN PAD
(H2934/G0447)
PH29345303303
GRAPHITE BRACKET SHAFT (G0581)
GRAPHITE BRACKET SHAFT
(H2934/G0447)
GRAPHITE BRACKET SHAFT (H2933)
302 PH29345302 37-1/2" GRAPHITE BRACKET
FEMALE (H2934/G0447)
44" GRAPHITE BRACKET FEMALE
(G0581)
44" GRAPHITE PRESSURE PLATE
(G0581)
37-1/2" GRAPHITE PRESSURE
PLATE (H2934/G0447)
25" GRAPHITE PRESSURE PLATE
(H2933)
GRAPHITE 37-3/4" x 3.54"
(H2934/G0447)
PH29345304304
306 PH29335306
PH29345306306
306 P05815306
PH29335308
PH29345308
P05815308308
308
308
