-8-
Model G0860/G0861/G0862 (Mfd. Since 10/18)
Model Number G0860 G0861 G0862
Operation
Dust Collector Type Two-Stage (Cyclone)
Approved Dust Types Wood
Filter Type Pleated Cartridge, Spun-Bond Polyester
Air Flow Performance 868 CFM @ 1.8" SP 1023 CFM @ 1.2" SP 1941 CFM @ 2.9" SP
Max. Static Pressure (at 0 CFM) 9.7" 10.9" 11.0"
Main Inlet Size 6" 7" 8"
Inlet Adapter Included Yes
Number of Adapter Inlets 2 3
Adapter Inlet Size 4" 4"
Machine Collection Capacity 2 Machines 3 Machines
Max. Material Collection Capacity 20 Gallons 35 Gallons
Bag Information
Number of Filter Bags 1
Number of Collection Drum Bags 1
Filter Bag Diameter 20"
Filter Bag Length 23"
Collection Drum Bag Diameter 30" 39"
Collection Drum Bag Length 41" 56"
Canister Filter Information
Number of Canister Filters 1
Filtration Rating 1 Micron
Canister Filter Diameter 14
1
⁄2"
Canister Filter Length 24" 39
3
⁄8"
Filter Surface Area 28.1 sq. ft. 45.2 sq. ft.
Impeller Information
Impeller Type Radial Fin
Impeller Size 12
3
⁄4" 13" 15"
Impeller Blade Thickness
1
⁄4"
1
⁄8"
Construction
Dust Collection Bags Clear Plastic
Base Steel
Frame Steel
Impeller Cast Aluminum Steel
Impeller Housing Steel
Body Steel
Collection Drum Steel
Paint Type/Finish Powder Coated
Manufacturer Specifications
Country of Origin Taiwan
Warranty 1 Year
Approx. Assembly & Setup Time 1 Hour
Serial Number Location ID Label on Impeller Housing
Sound Rating 78 dB 79 dB
ISO 9001 Factory Yes
