G1006/G1007 Mill/Drill -7-
REF PART # DESCRIPTION REF PART # DESCRIPTION
330 P1006330 SPRING BASE
332 P1006332 WORM GEAR
333 P1006333 FINE FEED HOUSING
334 P1006334 SPRING
335 P1006335 BEARING SPACER
336 P1006336 FEED HANDLE
337 P1006337 HANDLE BODY
339 P1006339 HANDLE ROD
340 P1006340 ROUND KNOB
341 P1006341 HANDLE BOLT
342 P1006342 HANDLE
343 P100634 HAND WHEEL
344 P1006344 GRADUATED DIAL
345 P1006345 SLEEVE
346 P6202 BEARING 6202
347 P1006347 WORM SHAFT
350 P1006350 HEAD WRENCH
351 P1006351 THUMB SCREW
352 P1006352 HEAD BOLT
354 P1006354 THREADED ROD
355 P1006355 PLATE W/ SCALE
356 P1006356 SWITCH
358 P1006358 ELEVATION CRANK
359 P1006359 WORM W/ SHAFT
360 P1006360 WORM GEAR
361 P1006361 WORM GEAR AXLE
362 P1006362 COMPRESSION SPRING
363 P1006363 PIN
366 P1006366 MOTOR BASE
367 P1006367 2 HP MOTOR
368 PK27M KEY 7mm x 7mm x 29mm
369A P1006369A TOP BELT COVER
370 P1006370 MOTOR PULLEY
371A PVB34 V-BELT 34''
372 P6204 BEARING 6204
373 P1006373 INTERMEDIATE PULLEY
374A PVB42 V-BELT 42''
375 P1006375 PULLEY SHAFT
376 P1006376 PULLEY SWING BASE
377 P1006377 CLIP PLATE
391A P1006391A SPECIAL NUT
392A P1006392A DEPTH INDICATOR NUT
393A P1006393A FIXED NUT
394A P1006394A SPECIAL NUT
395A P1006395A SPECIAL NUT
396A P1006396A SWITCH HOUSING
397A P1006397A SWITCH COVER
401 P1126201 HAND WHEEL
402 P1006402 GRADUATED DIAL
403 P51103 THRUST BEARING 51103
404 P1006404 FLANGE
405 P1006405 TABLE SCREW
406 P1006406 BASE
407 P1006407 SADDLE GIB
408 P1006408 COLUMN
410 P1006410 RACK
411 P1006411 COLUMN CAP
412 P1006412 GIB SCREW
413 P1006413 TABLE LOCK
414 P1006414 TABLE STOP
415 P1006415 TABLE BASE NUT
416 P1006416 SADDLE
417 P1006417 BOTTOM WAY COVER CLAMP
418 P1006418 WAY COVER W/ CLAMP
420 P1006420 CLUTCH
422 P1006422 LEFT FLANGE
423 P1005423 TABLE NUT
424 P1006424 TABLE SCREW
426 P1006426 RIGHT FLANGE
427 P1006427 TABLE GIB
428 P1006428 TABLE
429 P1006429 STOP BLOCK NUT
430 P1006430 SPACER
436 P1006436 HANDLE
662 P1006662 DRAW BOLT COVER
692 P1006692 BELT COVER LID
