Grizzly G1037Z Parts List

G1037Z 13" Planer/Moulder -43-
124 PN02 Hex Nut
5
⁄16-18
125 P1037Z125 Motor Mount
128 P1037Z128 57T Gear
129 P1037Z129 20T Gear
130 P1037Z130 Knife Setting Jig
130-1 PEC10M E-Clip 9mm
130-2 P1037Z130-2 Knife Setting Jig Foot
130-3 P1037Z130-3 Knife Setting Jig Rod
131 P1037Z131 “L” Gauge
132 P1037Z132 17 x 32 Wrench
133 PWR1012 10 X 12 Wrench
134 PWR1113 11 X 13 Wrench
135 PAW03M Hex Wrench 3mm
136 PAW04M Hex Wrench 4mm
137 PAW05M Hex Wrench 5mm
138 PAW06M Hex Wrench 6mm
139 P1037Z139 Screwdriver
140 P1037Z140 Drift
143 P1037Z143 Wire Clip
144 P1037Z144 Pulley
145 PW01M Flat Washer 8mm
146 PW03M Flat Washer 6mm
147 PW01M Flat Washer 8mm
148 PB09 Hex Bolt
5
⁄16-18 x
1
⁄2
149 P1037Z149 Motor Cord
150 P1037Z150 Left Moulding Fence
151 P1037Z151 Right Moulding Fence
152 P1037Z152 Bracket
153 P1037Z153 Knob (Male) M6-1 x 20
154 PLABEL-4 Z Series Label
155 P1037Z155 Ear Protection Label
156 P1037Z156 Respirator/Glasses Label
157 G9987 Grizzly Name Plate
158 P1037Z158 Cutterhead Cover Label
159 PLABEL-14 Electricity Label
160 PLABEL-26 Unplug Label
161 PLABEL-12 Read Manual Label
162 P1037Z162 Machine ID Label
163 P1037Z163 31T Gear
164 P1037Z164 46T Gear
107 PSS02M Set Screw M6-1 x 6
108 P1037Z108 Sprocket
109 PCB05 Carriage Bolt
5
⁄16-18 x
3
⁄4
110 P1037Z110 Motor
110-1 P1037Z110-1 Fan Cover
110-2 P1037Z110-2 Motor Fan
110-3 P1037Z110-3 Capacitor Cover
110-4 PC400A Capacitor 400MFD 125V
111 PW01M Flat Washer 8mm
113 P1037Z113 Switch Assembly
113-1 PS21M Phlp Hd Scr M4-.7 x 15
113-2 PW05M Flat Washer 4mm
113-3 P1037Z113-3 Switch Cord
113-4 P1037Z113-4 Switch Plate
113-5 PN04M Hex Nut M4-.7
113-6 PHTEK28M Tap Screw M4 x 25
113-7 P1037Z113-7 Switch Cover
113-8 P1037Z113-8 Strain Relief
113-9 P1037Z113-9 Power Cord
113-10 P1037Z113-10 Strain Relief
113-11 PTLW06M Ext Tooth Washer 4mm
113-12 P1037Z113-12 Switch Box
113-13 P1037Z113-13 Switch
114 P1037Z114 Knob (Female) M8-1.25
115 P1037Z115 Pulley Cover
116 P1037Z116 Stud
117 P1037Z117 Fence Guide Rod Bracket
118 P1037Z118 Fence Guide Rod
119 P1037Z119 Pulley
120 P1037Z120 Handle
121 P1037Z121 Stand Assembly
121-1 P1037Z121-1 Lower Side Brace
121-2 P1037Z121-2 Leg E
121-3 P1037Z121-3 Leg F
121-4 P1037Z121-4 Lower End Brace
121-5 P1037Z121-5 Upper End Brace
121-6 P1037Z121-6 Upper Side Brace, L
121-7 P1037Z121-7 Upper Side Brace, R
122 PCB02 Carriage Bolt
5
⁄16-18 x
1
⁄2
123 PW01M Flat Washer 8mm
REF PART # DESCRIPTION REF PART # DESCRIPTION
