Grizzly G4003 Read This First

Model G4002/G4003 (Mfd. Since 3/14)
-55-
Tailstock Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
701 P4002701 CENTER 715 P4002715 HEX NUT M12-1.75
702 P4002702 KEY 8 X 30 716 P4002716 HANDLE
703 P4002703 QUILL 717 P4002717 LOCK SCREW
704 P4002704 TAIL STOCK 718 P4002718 LOCK SHAFT
705 P4002705 BASE 719 P4002719 HANDLE
706 P4002706 CAP SCREW M10-1.5 X 50 720 P4002720 SHAFT
707 P4002707 SCREW 721 P4002721 ROLL PIN 5 X 30
708 P4002708 PIN B4 X 8 722 P4002722 COLLAR
709 P4002709 THRUST BEARING 8101 723 P4002723 SHAFT
710 P4002710 BRACKET 724 P4002724 BASE SHOE BLOCK
711 P4002711 INDEX RING 725 P4002725 FLAT WASHER 12MM
712 P4002712 CAP SCREW M6-1 X 20 726 P4002726 HEX NUT M12-1.75
713 P4002713 HAND WHEEL 727 P4002727 NUT
714 P4002714 HANDLE 728 P4002728 INDEX
