1. MACHINE SPECIFICATIONS CONTINUED
1.1 TABLE OF SPECIFICATIONS CONTINUED
1.2 OPERATOR CONTROLS
• The handlebars provide access to most of the machine controls.
• Turning the handlebars while standing on the operator platform provides steering control.
• Squeezing the throttle lever on the right side of the handlebars provides speed control.
• Depressing the brake pedal on the operator platform provides braking control.
• The spray control lever controls liquid ow from the tank to the nozzles.
• The gate lever controls the ow of granular product out of the hopper.
• The engine ignition switch controls the operation or shutdown of the engine.
• The spray control knob controls liquid ow between the trim and broadcast spray nozzles.
• The spread control lever controls the center of the spread pattern of granular product.
• The gate stop on the front of the hopper controls the maximum gate opening for granular product.
2. GENERAL OPERATIONAL SAFETY
2.1 PROPOSITION 65 STATEMENT
WARNING
This product can expose you to chemicals including gasoline engine exhaust, which is known to the State of
California to cause cancer, and carbon monoxide, which is known to the State of California to cause birth de-
fects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
Read these safety rules and follow them closely. Failure to obey these rules could result in loss of control of the
unit, severe personal injury or death to you, or bystanders, or damage to property or equipment.
DIMENSIONS
• Overall length: 54.0” (137 cm).
• Overall width: 35.5” (90 cm).
• Overall height: 49.0” (124 cm).
• Weight: 375 lb. (170 kg) dry, 600 lb.
(272 kg) full, 800 lb. (363 kg) full with
200 lb. (91 kg) rider.
• Overall length: 58.0” (147 cm).
• Overall width: 35.5” (90 cm).
• Overall height: 50.5” (128 cm).
• Weight: 450 lb. (204 kg) dry, 785 lb.
(356 kg) full, 985 lb. (447 kg) full with
200 lb. (91 kg) rider.
ELECTRICAL SYSTEM
• Charging system: N/A
• Charging capacity: N/A
• Safety interlock system: This ma-
chine is equipped with a neutral safety
start module. To start the engine, the
transmission must be in the neutral (N)
position.
• Charging system: N/A
• Charging capacity: N/A
• Safety interlock system: This ma-
chine is equipped with a neutral safety
start module. To start the engine, the
transmission must be in the neutral (N)
position.
PATHFINDER PATHFINDER XC
