Growatt 2000-US User Manual

Input data
Specifications
Growatt
1500-US
Model
Growatt
2000-US
Growatt
3000-US
Max. DC power
1800W 2300W 3200W
Max. DC voltage
450V 500V 500V
Start voltage
150V 150V 150V
DC nominal voltage
360V 360V 360V
PV voltage range
100V-450V 100V-500V 100V-500V
Output data
AC nominal voltage;
range
Default:240V single phase, optional:208 single phase
183-228V@208V 211-264@240V
Phase shift (cosφ)
1 1 1
THDI < 3% < 3% < 3%
Single phase Single phase Single phase
AC connection
MPP voltage range
120V-400V 120V-450V 120V-450V
Number of independent
MPP trackers/strings per
MPP tracker
1/1 1/ 21/ 2
Max. input current of
the MPP tracker
12A
14A 17A
Nominal AC
output power
Max. output current
8A/7.8A 9.7A/9.4A 15A/14.2A
AC grid frequency;
range
60Hz;59.3-60.5Hz 60Hz;59.3-60.5Hz 60Hz;59.3-60.5Hz
Efficiency
Max. efficiency
97% 97% 97%
CEC efficiency
96% 96.5% 96.5%
MPPT efficieny
99.5% 99.5% 99.5%
Protection devices
DC reverse polarity
protection
yes yes yes
DC switch ratiing for
each MPPT
yes yes yes
Output Over current
protection
yes yes yes
Output Overvoltage
Protection-varistor
yes yes yes
Ground fault monitoring
yes yes yes
Grid monitoring
yes yes yes
Integrated all - pole sensitive
leakage current monitoring unit
yes yes yes
General Data
Dimensions (W / H / D)
in mm
360/465/165
Weight
14.6KG 15.1KG 15.9KG
Operating
temperature
range
-25...+60℃
(-13...+ 140°F)
with derating above
45°C（113°F）
-25...+60℃
(-13...+ 140°F)
with derating above
45°C（113°F）
-25...+60℃
(-13...+ 140°F)
with derating above
45°C（113°F）
Noise emission
(typical)
≤ 25 dB(A) ≤ 25 dB(A) ≤ 25 dB(A)
Altitude
Up to 2000m(6560ft) without power derating
49 50
1500W@208Vac
1650W@240Vac
15 Technical Data
15.1 Specification
1800W@208Vac
2000W@240Vac
2500W@208Vac
2800W@240Vac
360/465/165
360/465/165
