Growatt MAC 36KTL3-XL User Manual

27
28
7.3.1 Boot Display
7.3.2 OLED Display Wake Up
7.3.3 Function Setting
7.3.3.1 Select Protection Voltage Level
When the inverter is turned on, the OLED display interface is as follows:
Connect OK
CUTDOWN
30S
PV1
XXXvXXXXw
PV2
XXXvXXXXw
Set
Parameter
Grid
XXXvXXXHz
More info
Growatt
PV inverter
Power
XXXXw
Etotal
XXXXw
Etoday
XXXkWh
After the inverter works normally for 5 minutes, the OLED display will be automatically
turned off. At this time, the OLED has no display, the leaf of the indication window is
green, and the display data needs to be viewed or set. The OLED can be redisplayed by
touch operation.
All settings interface is as follows:
WideVolt Set
1 2 3
Password
111
Enable|Nline
Exporlimit
OFF ON
General
Advanced
Set Date
2018-12-14
Set Time
12:30:30
Set Comaddr
1
Set Language
English
General
Advanced
Set
Parameter
Reset factory
YES NO
WideVolt Set
WideVolt Set
1 2 3
Set OK
The inverter is factory set to CQC standard regulations, customers can choose different
voltage protection levels according to the actual situation; single touch switching
voltage level, continuous touch twice to confirm the setting.
1 standard
2 wide voltage level 2
3 wide voltage level 3
Figure 7.5
Figure 7.7
Figure 7.6
The inverter can support multiple touch mode modes: single touch, two
consecutive touches, three consecutive touches, and long press 5S. Different
types of taps have different functions. Advanced setup password: 111
Touch mode
definition
single
Move, turn page or current number plus 1
Two consecutive times
Enter setup mode, confirm settings
Three consecutive times
Return to the previous display interface
Long press 5S
Current data is zeroed
