Growatt MOD 11KTL3-X User Manual

Index
1 Notes on this manual
2 Safety
3 Product overview
3.1 Appearance overview
3.2 Dimensions
3.3 Storage environment
1.1 Validity
1.2 Applicable personnel
1.3 Symbols in this document
2.1 Product description and features
2.2 Qualification of skilled person
2.3 Safety instruction
4 Unpacking inspection
5 Installation
5 1 Basic installation requirements.
5.2 Mounting wall mount
5.3 Installing the inverter
6.1 Security
6.2 AC side wiring
6.3 DC side wiring
6.4 Connect the signal cable
6.5 Grounding the inverter
6.6 Active power control with smart
meter,CT or ripple control signal
receiver
6.7 GFCI(Standard)
6.8 Inverter demand response modes
(DRMS)
6.9AFCI(Optional)
6 Inverter wiring

Growatt MOD 11KTL3-X Specifications

General

Product type	-
Maximum power	11000 W
Output current	18.3 A
Output frequency	50/60 Hz
MPP voltage range	140 - 1000 V
Number of strings per MPPT	1
Output power capacity (max)	11 kVA
Input operation voltage (max)	1100 V
Input operation voltage (min)	160 V
Maximum input current per MPPT	13 A
Output operation voltage (max)	440 V
Output operation voltage (min)	340 V
Total Harmonic Distortion (THD)	3 %
Number of maximum power point tracking (MPPT)	2
Operating temperature (T-T)	-25 - 60 °C
Built-in display	Yes
Display technology	OLED
Product color	White
Overvoltage category	CAT II
Power protection features	Over voltage, Short circuit
International Protection (IP) code	IP66

Weight and Dimensions

Depth	178 mm
Width	425 mm
Height	387 mm
