14) Remove protective film from the both sides of the

ACRYLIC MARQUEE (O). Assemble the marquee by

placing the BOTTOM MARQUEE CHANNEL (D), TOP

MARQUEE CHANNEL (E) and ACRYLIC MARQUEE (O)

into position.

15) Plug the 14-pin connector from the WIRING

HARNESS into the CONTROL PANEL ASSEMBLY (B).

Set the CONTROL PANEL ASSEMBLY (B) into place.

See "Optional Control Panels" if

using any of the optional panels.

16) Set the FRONT (C1) into position.

(continued)

ASSEMBLY INSTRUCTIONS
