GRS BUILD-A-CADE - Back Panel Connections

16
26) Attach the MicroSD card connector to the BACK
PANEL (L1) using 2 - M2.3x6mm screws (S4).
27) Attach the HDMI port to the BACK PANEL (L1) using
2 - M3x8mm screws (S5).
28) Plug the AUDIO CABLE (W3) into the audio jack on
the circuit board.
(continued)
ASSEMBLY INSTRUCTIONS
