13. Technical data
Flow rate(Q)
Max. 13.6 gpm (3.1
m
3
/h)
Head (H) Max. 18 ft (5.5 m)
Supply voltage
1 × 115 V, ± 10 %, 60
Hz
Motor protection
The pump requires no
external motor
protection.
Power usage
(approximate)
Min. 2 - max. 38 W
Enclosure class
Indoor use only.
Enclosure type 2.
Insulation class F
Ambient temperature 32-131 °F (0-55 °C)
Liquid temperature
36-203 °F (2-95 °C)
2)
Relative humidity Max. 95 %
Max. outlet pressure
175 psi (12 bars) (1.2
MPa)
Sound pressure level < 25 dB(A)
Approvals
cULus and FCC
The product complies
to limits for class B
digital device, pursuant
to Part 15 of the FCC
Rules.
Port-to-port length 5.31" (135 mm)
Pump housing Stainless steel
Connection type
3/4" NPT(M) × 3/4"
NPT(F)
Connections
Comfort Valve: ½"
NPS(M)
Flex hose: ½"
NPS(F) × ½"
NPS(F) × 12"
2)
Hard water deposits can occur at temperatures over
140 °F (60 °C).
Inlet pressure
Liquid temperature
[°F (°C)]
Min. inlet pressure
[psi (bar)]
167 (75) 0.75 (0.05)
203 (95) 7.25 (0.5)
230 (110) 15.7 (1.08)
14. Disposing of the product
This product or parts of it must be disposed of in
an environmentally sound way.
1. Use the public or private waste collection
service.
2. If this is not possible, contact the nearest
Grundfos company or service workshop.
See also end-of-life information at
www.grundfos.com/product-recycling.
15. Document quality feedback
To provide feedback about this document, scan
the QR-code using your phone’s camera or a QR
code app.
Click here to submit your feedback
24
English (US)
