Grundfos CIM 500

2. Applications
The CIM 500 Ethernet module enables data
transmission between an Industrial Ethernet network
and a Grundfos product.
The module supports various Industrial Ethernet
protocols.
The module is fitted in the product to be
communicated with in a CIU 90x to form a CIU 50x or
in an E-box to form an E-box 500.
Retrofitting of the module is described in the
installation and operating instructions of the Grundfos
product.
Configuration is done via the built-in webserver
, using
a standard web browser on a PC.
You can download the specific functional profile for
the product in question from Grundfos Product
Center.
Related information
3.3 Selection of Industrial Ethernet protocol
2.1 Abbreviations
APDU Application Protocol Data Unit.
ARP
Address Resolution Protocol. Translates
IP addresses to MAC addresses.
CAT5
Ethernet cable type with four twisted-pair
cables.
CAT5e
Enhanced CAT5 cable with better
performance.
CAT6
Ethernet cable compatible with CAT5 and
CA
T5e, and with very high performance.
CIM Communication Interface Module.
CIU Communication Interface Unit.
DHCP
Dynamic Host Configuration Protocol.
Used to configure network devices so
that they can communicate via an IP
network.
DNS
Domain Name System. Used to resolve
host names to IP addresses.
E-box
Extension Box. Used as a
communication interface between a
Grundfos DDA dosing pump (small) and
a fieldbus.
GENIpro
Grundfos Electronics Network
Intercommunication protocol. Proprietary
Grundfos fieldbus protocol.
GiC Grundfos iSOLUTIONS Cloud.
GND Ground.
GRM Grundfos Remote Management.
HTTP
Hyper Text Transfer Protocol. The
protocol commonly used to navigate
the W
orld Wide Web.
IANA Internet Assigned Numbers Authority.
IP Internet Protocol.
LED Light-emitting diode.
MAC
Media Access Control. Unique address
for a piece of hardware.
MDI Medium Dependent Interface.
Ping
Packet InterNet Groper. A software utility
that tests connectivity between two
TCP/IP hosts.
PLC Programmable Logic Controller.
RJ45
Registered Jack #45, also called 8P8C
modular connector type. Connects four
twisted-pair cables. Most common
Ethernet connector type.
SELV Separated or Safety Extra-Low Voltage.
SELV-E
Separated or Safety Extra-Low Voltage
with earth.
TCP
Transmission Control Protocol. Protocol
for Internet communication and Industrial
Ethernet communication.
UDP User Datagram Protocol.
URL
Uniform Resource Locator. The IP
address used to connect to a server.
VPN Virtual Private Networks.
