Grundfos CMB-SP Booster PM2 User Manual

English (GB)
4
English (GB) Installation and operating instructions
Supplement to quick guide.
CONTENTS
Page
1. Symbols used in this document
2. System sizing
3. Mechanical installation
1. Symbols used in this document
4
2. System sizing
4
3. Mechanical installation
4
4. Electrical connection
5
5. Startup
5
6. Alarms
5
6.1 Anti-cycling
5
6.2 Auto reset
5
7. Fault finding chart
6
8. Disposal
8
Warning
Prior to installation, study the quick guide
carefully. Installation and operation must
comply with local regulations and accepted
codes of good practice.
Warning
The use of this product requires
experience with and knowledge of the
product.
Persons with reduced physical, sensory or
mental capabilities must not use this
product, unless they are under supervision
or have been instructed in the use of the
product by a person responsible for their
safety.
Children must not use or play with this
product.
Warning
If these safety instructions are not
observed, it may result in personal injury!
Warning
If these instructions are not observed, it
may lead to electric shock with consequent
risk of serious personal injury or death.
Caution
If these safety instructions are not
observed, it may result in malfunction or
damage to the equipment!
Note
Notes or instructions that make the job
easier and ensure safe operation.
Warning
The system in which the CM Booster is
incorporated must be designed for the
maximum pump pressure.
Caution
The default setting will cause the pump not
to stop until it reaches its maximum
pressure.
Warning
Before starting any work on the product
make sure that the power supply has been
switched off and that it cannot be
accidentally switched on.
