Grundfos CMBE 10-54 User Manual

Terminal Type Function
23 GND
Protective earth.
Pressure sensor: GND, 0 V. Connect the
green wire to this terminal.
25 GDS TX Grundfos Digital Sensor output
24 GDS RX Grundfos Digital Sensor input
7 AI2
External sensor.
Pressure sensor: Temperature signal, 0.5 to
3.5 V. Connect the yellow wire to this terminal.
12
English (GB)

Grundfos CMBE 10-54 Specifications

General

Brand	Grundfos
Model	CMBE 10-54
Category	Water Pump
Language	English
